Front Seat Belt Guide Replacement

Fig 1: Front Seat Belt Guide
GM1551165Courtesy of GENERAL MOTORS CORP.
Callout Component Name
Fastener Tightening Specifications:  Refer to Fastener Tightening Specifications .
Preliminary Procedures:
Remove the head restraint. Refer to Driver or Passenger Seat Head Restraint Replacement .
1 Guide, Seat Shoulder Belt
Tip:  Cut the retainers that secure the should belt guide to the head restraint to remove and install new retainers to reinstall.
