Special Tools

WARNING: This page is about a different variant/trim than selected.

Illustration	Tool Number/ Description
Courtesy of GENERAL MOTORS CORP.	DT 47678 Transmission Holding Fixture
Courtesy of GENERAL MOTORS CORP.	DT 47678-10 Transmission Holding Fixture Adapters
Courtesy of GENERAL MOTORS CORP.	DT 47722 Shift Rail Bushing Remover/Installer
Courtesy of GENERAL MOTORS CORP.	DT 47723 Output Shaft Bearing Installer
Courtesy of GENERAL MOTORS CORP.	DT 47724 Output Shaft Bearing Cup Installer
Courtesy of GENERAL MOTORS CORP.	DT 47725 Extension Housing Bearing Cup Installer
Courtesy of GENERAL MOTORS CORP.	DT 47726 Counter Shaft Rear Bearing Installer
Courtesy of GENERAL MOTORS CORP.	DT 49027 Coil Pin Remover and Installer
Courtesy of GENERAL MOTORS CORP.	J 2619-01 Slide Hammer
Courtesy of GENERAL MOTORS CORP.	J 8001-3 Dial Indicator
Courtesy of GENERAL MOTORS CORP.	J 8092 Driver Handle
Courtesy of GENERAL MOTORS CORP.	J 22912-B Split Plate Bearing Puller
Courtesy of GENERAL MOTORS CORP.	J 26900-12 Dial Indicator 1-10 mm
Courtesy of GENERAL MOTORS CORP.	J 26900-13 Magnetic Indicator Base
Courtesy of GENERAL MOTORS CORP.	J 26941 Bushing and Bearing Remover 3-4 in
Courtesy of GENERAL MOTORS CORP.	J 36614 Inner Pinion Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 41816 Crankshaft Balancer Remover
Courtesy of GENERAL MOTORS CORP.	J 44749 Split Plate Bearing Gear Puller
Courtesy of GENERAL MOTORS CORP.	J 44765 Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 45012 Holding Fixture
