Front Side Door Sill Trim Plate Replacement

Fig 1: View Of Front Side Door Sill Plate

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
Fastener Tightening Specifications:  Refer to Fastener Tightening Specifications .
1	Plate Assembly, Front Side Door Sill Trim
2	Clip, Side Door Sill Trim (Qty: 3)
