5th/6th Speed Driven Gear Removal

WARNING: This page is about a different variant/trim than selected.
    Fig 1: View Of Special Tools J 8433 & J 39431-1
    GM1746800Courtesy of GENERAL MOTORS CORP.
  1. Install J 8433:  puller (1),J 39431:  remover and bolts (3) and J 39431-4 (2) on the 5th speed driven gear.
  2. Remove the 5th speed driven gear.
