Shift Indicator Lamp
Courtesy of GENERAL MOTORS CORP. Shift Indicator Lamp Connector Terminal Identification
| Pin |
Wire |
Circuit |
Function |
| 1 |
D-GN |
44 |
Instrument Panel Lamps Dimming Control |
| 2 |
BN/WH |
309 |
Right Park Lamp Supply Voltage |
Connector Part Information
- OEM: 94797519
- Description: 2-Way F (BK)
|
