20. Engine Front Cover Removal

Engine Front Cover Removal (RPO LY2/LMF) (4.8L and 5.3L)





1. Remove the front cover bolts (1).
2. Remove the front cover (2) and gasket (3).
3. Discard the front cover gasket.




4. Remove the oil seal (4).
5. Remove the bolts (1, 6), camshaft position (CMP) sensor (2), and wire harness (5).
6. Remove the O-ring (3) from the sensor, as required.
