Liftgate Latch Replacement

Fig 1: Latch Replacement - Liftgate
GM1601430Courtesy of GENERAL MOTORS CORP.
Liftgate Latch Replacement

Callout Component Name
Preliminary Procedure:
Remove the liftgate trim panel. Refer to Liftgate Trim Panel Replacement .
1 Liftgate Latch Bolts (Qty: 3)
NOTE: Refer to Fastener Notice .

Tighten:  10 N.m (89 lb in)
2 Liftgate Latch
Tip:  Disconnect the electrical connectors.
