Instrument Panel Inflatable Restraint Module Indicator Replacement

Fig 1: Indicator Replacement - Inflatable Restraint IP Module

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
CAUTION: Replace the passenger presence system as a complete assembly to prevent possible injury to the occupant. All the components in the service kit are assembled and calibrated as a unit. Using only some of the components in the service kit will cause the passenger presence system to operate improperly.
1	Instrument Panel (I/P) Cluster Trim Plate Bezel Refer to Instrument Panel Cluster Trim Plate Bezel Replacement . Tip: Disconnect the electrical connector.
2	Inflatable Restraint I/P Module Indicator Assembly
