Camshaft Position Sensor Replacement

WARNING: This page is about a different variant/trim than selected.

Fig 1: View Of Camshaft Position Sensor

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedures Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection . Remove the radiator fan and clutch. Refer to Fan Replacement .
1	Camshaft Position Sensor Electrical Connector
2	Camshaft Position Sensor Bolt Tighten: 10 N.m (89 lb in)
3	Camshaft Position Sensor Tip: Lubricate the camshaft position sensor O-ring with engine oil prior to installation.
