Installation Procedure

WARNING: This page is about a different variant/trim than selected.
    Fig 1: View Of Camshaft Cover
    GM1578306Courtesy of GENERAL MOTORS CORP.
    NOTE: Refer to Fastener Notice .
  1. Install the camshaft cover and bolts.

    Tighten:  Tighten the bolts to 10 N.m (89 lb in).

    2. Fig 2: View Of Engine Harness Clips
    GM1656114Courtesy of GENERAL MOTORS CORP.
  2. Install the ignition coils. Refer to Ignition Coil(s) Replacement .
  3. Install the engine harness clips (1 and 2) to the cover.
    4. Fig 3: Identifying Camshaft Position Actuator Solenoid Valve Electrical Connectors
    GM1647538Courtesy of GENERAL MOTORS CORP.
  4. Connect the intake (2) and exhaust (2) camshaft position actuator solenoid valve electrical connectors.
    5. Fig 4: IP Harness Pass Through To Engine Compartment Connectors
    GM581306Courtesy of GENERAL MOTORS CORP.
  5. Install the PCV hose to the cover.
  6. Position the PCV hose clamp.
  7. Install the intake manifold cover. Refer to Intake Manifold Cover Replacement .
