Removal Procedure

WARNING: This page is about a different car, the 2007 Pontiac G5 Pursuit, 2007 Pontiac G5, and 2007 Chevrolet Cobalt. However, it is still accessible from the selected car via links, so may be relevant.

IMPORTANT: The factory equipped welded exhaust muffler pipe can be cut and reused when installing a service muffler, if the muffler pipe is in acceptable condition.

Fig 1: View Of Exhaust Muffler (LSJ)

Courtesy of GENERAL MOTORS CORP.

Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle .
Support the exhaust muffler.
Cut the exhaust muffler pipe just forward of the weld at the front of the exhaust muffler using a suitable exhaust pipe cutter.
Remove the muffler insulator from the underbody hanger and remove the exhaust muffler.
Deburr the muffler pipe end as necessary.
