Installation Procedure

WARNING: This page is about a different variant/trim than selected.
    Fig 1: View Of Fuel Feed Pipe At The Fuel Filter Inlet
    GM892640Courtesy of GENERAL MOTORS CORP.
  1. Install the EVAP canister to the EVAP canister bracket.
  2. Connect the fuel tank EVAP pipe to the canister.
  3. Connect the chassis EVAP purge pipe to the EVAP canister.
  4. Connect the vent hose to the canister.
  5. Lower the vehicle.
