Removal Procedure

WARNING: This page is about a different car, the 2008 Suzuki Swift +, 2008 Pontiac Wave, and 2008 Chevrolet Aveo. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: View of Inside Lock Rods From Door Handle and Lock
    GM1248269Courtesy of GENERAL MOTORS CORP.
    CAUTION: Refer to Battery Disconnect Caution .
  1. Disconnect the negative battery cable.
  2. Remove the rear door glass. Refer to Rear Side Door Window Replacement .
  3. Remove the nuts and the regulator.
  4. Disconnect the electrical connector.
