Installation Procedure

WARNING: This page is about a different car, the 2008 Suzuki Swift +, 2008 Pontiac Wave, and 2008 Chevrolet Aveo. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: View of Electric Control Rearview Mirror Electrical Connector and Outside Mirror Assembly
    GM1248495Courtesy of GENERAL MOTORS CORP.
  1. Install the cargo area side trim panel with the clips.
  2. Install the rear compartment trim panel. Refer to Rear Compartment Trim Panel Replacement (Notchback)  or Rear Compartment Trim Panel Replacement (Hatchback) .
