Manual Transmission Schematics (Notchback)

WARNING: This page is about a different car, the 2008 Pontiac Wave. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Manual Transmission Schematic (Notchback)
GM1750309Courtesy of GENERAL MOTORS CORP.
