Removal Procedure

  1. Open the instrument panel (I/P) compartment door to access the right I/P trim panel (3).
  2. Remove the I/P accessory trim plate. Refer to TRIM PLATE REPLACEMENT - INSTRUMENT PANEL (I/P) ACCESSORY (CHEVROLET)  or TRIM PLATE REPLACEMENT - INSTRUMENT PANEL (I/P) ACCESSORY (PONTIAC)  .
  3. Remove the screws (1) from the RH I/P trim panel (3).
  4. Remove the right I/P trim panel (3) from the I/P (2).
    Fig 1: Removing Right I/P Trim Panel From I/P
    G01559269Courtesy of GENERAL MOTORS CORP.
