Test Description

The numbers below refer to the step numbers on the diagnostic table:

  1. 2. Suspension components that are not operating properly may cause a disturbance to the vehicle during application of the brake system.
  2. 3. Steering components that are not operating properly may cause a disturbance to the vehicle during application of the brake system.
Fig 1: Braking Action Uneven - Pulls to One Side
G01711037Courtesy of GENERAL MOTORS CORP.
