Installation Procedure

  1. Install the stud into the hole in the wheel hub.
    1. 1.1. Start the serrated stud into the hole in the wheel hub by tapping lightly with a hammer.
    2. 1.2. The stud must be square with the wheel hub before pressing on the arbor press.
  2. Install the rotor. Refer to Wheel Hub, Bearing, and Seal Replacement (RWD Pickup)  or Wheel Hub, Bearing, and Seal Replacement (4WD Pickup and Utilities) .
    Fig 1: Installing Stud Into Hole In Wheel Hub (RWD)
    G01670483Courtesy of GENERAL MOTORS CORP.
