Removal Procedure

  1. Raise and suitably support the vehicle with safety stands. Refer to LIFTING & JACKING THE VEHICLE in General Information.
  2. Remove the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  3. Remove the to the stabilizer shaft link retaining nut.
  4. Remove the retainers from the stabilizer shaft link bolt.
  5. Remove the grommets from the stabilizer shaft link bolt.
  6. Remove the following parts from the stabilizer shaft link bolt:
    Fig 1: Removing Tire And Wheel Assembly (RWD)
    G01670381Courtesy of GENERAL MOTORS CORP.
    1. 6.1. The grommet
    2. 6.2. The retainer
    3. 6.3. The spacer
    4. 6.4. The retainer
    5. 6.5. The grommet
