Test Description

WARNING: This page is about a different variant/trim than selected.

The numbers below refer to the step numbers on the diagnostic table.

2. Determine the position of the Front Axle Switch.

3. Helps determine if the front axle will not engage.

4. Helps determine if the front axle will not disengage.

Fig 1: Transfer Case Shift Control Switch Indicators Flash Continuously
G01671200Courtesy of GENERAL MOTORS CORP.
