Installation Procedure

WARNING: This page is about a different car, the 2004 GMC Sierra, 2004 GMC Cab & Chassis Sierra, 2004 Chevrolet Silverado, and 2004 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the auxiliary battery tray.
    NOTE: Refer to Fastener Notice in Cautions and Notices
  2. Install the battery tray bolt and nuts.

    Tighten:

    • Tighten the bolt to 9 N.m (80 lb in).
    • Tighten the nuts to 25 N.m (18 lb ft).

    3. Fig 1: View Of Auxiliary Battery Tray
    GM368343Courtesy of GENERAL MOTORS CORP.
  3. Set the surge tank into position.
  4. Install the surge tank nut and bolt.

    Tighten:  Tighten the bolt and nut to 9 N.m (80 lb in).

  5. Install the auxiliary battery. Refer to Battery Replacement - Auxiliary .
