Removal Procedure

WARNING: This page is about a different car, the 2002 Oldsmobile Bravada, 2002 GMC Envoy XL, 2002 GMC Envoy, and 2002 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise the vehicle. Refer to Lifting and Jacking the Vehicle in General Information.
  2. Remove the tire and wheel assembly. Refer to Tire and Wheel Removal and Installation in Tires and Wheels.
  3. Remove the rear axle housing cover and the gasket. Refer to Rear Axle Housing Cover and Gasket Replacement .
  4. Remove the axle shaft. Refer to Rear Axle Shaft Replacement .
  5. Remove the axle shaft seal and/or the bearing from the axle housing using the J 44685 (1) and the J 2619-O1 (2).
    6. Fig 1: Removing Axle Shaft Seal And/Or Bearing From Axle Housing
    G01705389Courtesy of GENERAL MOTORS CORP.
