Diagnostic Aids
WARNING: This page is about a different car, the 2002 Oldsmobile Bravada, 2002 GMC Envoy XL, 2002 GMC Envoy, and 2002 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
Operating the vehicle on extremely rough terrain can set DTC C0223, C0227 or C0229 even if the system is functioning normally.
Thoroughly inspect connections or circuitry that may cause an intermittent malfunction. Refer to Testing for Intermittent and Poor Connections , Connector Repairs , Testing for Electrical Intermittents and to Wiring Repairs in Wiring Systems.
If the customer's concern is that the ABS indicator is on only during humid conditions such as rain, snow or vehicle wash, thoroughly inspect the wheel speed sensor circuits for signs of water intrusion. Use the following procedure in order to help isolate the problem area:
- Spray the suspected area with a 5 percent salt water solution (10 grams of salt to 200 ml of water or 2 teaspoons of salt to 12 oz of water).
- Drive the vehicle at a speed greater than 19 km/h (12 mph) for at least 30 seconds.
Repair or replace the suspect harness if the DTC sets.
