Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the high mount stoplamp (endgate window-mounted only). Refer to HIGH MOUNTED STOP LAMP REPLACEMENT (UTILITY - ENDGATE WINDOW) or HIGH MOUNTED STOP LAMP REPLACEMENT (UTILITY - ROOF MOUNTED) or HIGH MOUNTED STOP LAMP REPLACEMENT (PICKUP) in Lighting Systems.
  2. Open the endgate window.
  3. Mark the location of the endgate window hinges on the body for proper alignment at installation.
  4. Disconnect the rear window defogger connectors, if equipped.
  5. Remove the endgate window struts. Refer to STRUT REPLACEMENT - END GATE .
    Fig 1: Endgate Window Struts
    G01478290Courtesy of GENERAL MOTORS CORP.
  6. Remove the bolts that retain the endgate window hinges to the vehicle.
  7. With an assistant, remove the endgate window from the vehicle.
