Installation Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the endgate window latch.

    Ensure that the latch is properly aligned with the marks made during disassembly.

    NOTE: Refer to FASTENER NOTICE in Cautions and Notices.
  2. Install the nuts that retain the endgate window latch to the endgate window latch support.

    Tighten

    Tighten the nuts to 10 N.m (88 lb in).

  3. Connect the electrical connectors, as needed.
  4. Install the endgate cover. Refer to END GATE COVER REPLACEMENT .
    Fig 1: Endgate Window Latch
    G01478269Courtesy of GENERAL MOTORS CORP.
