Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.

Remove the rear window garnish molding.

Fig 1: Rear Window Garnish Molding
Courtesy of GENERAL MOTORS CORP.
Remove the jack storage cover.
Use the J 38778 in order to release the rear carpet panel retainers.
Remove the rear inner panel carpet from the vehicle.

Fig 2: Removing Rear Inner Panel Carpet From Vehicle
Courtesy of GENERAL MOTORS CORP.
