Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Use a flat-bladed tool in order to carefully pry the seal assembly away from the flange.
  2. Remove the seal from the hood.
    Fig 1: Removing Seal From Hood
    G01477582Courtesy of GENERAL MOTORS CORP.
