Compass Calibration
WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.
Important: Before calibrating the compass, drive the vehicle to a area that is magnetically clean, and free of large metallic objects.
- Turn ON the ignition.
- Press the MODE button in order to advance to the COMP/TEMP mode.
- Simultaneously depress and hold the US/MET and MODE buttons until a C is displayed, in approximately 10 seconds.
- Release both buttons.
- Drive the vehicle in circles at a speed of less than 8 km/h (5 mph) until the C is replaced by a proper vehicle heading. The calibration procedure is now complete.
