Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the screw at the front of the console that retains the sunroof console to the roof.
  2. Pull downward on the rear of the console in order to remove the sunroof console from the roof.
  3. Disconnect the electrical connectors (1, 5, 6) as needed.
  4. Remove the screw that retains the sunroof console mounting bracket to the roof.
    Fig 1: Removing Sunroof Console Mounting Bracket To Roof Retaining Screws
    G01476638Courtesy of GENERAL MOTORS CORP.
