Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the interior trim panel. Refer to TRIM PANEL REPLACEMENT -- END GATE or TRIM PANEL REPLACEMENT -- LIFT GATE in Body Rear End.
  2. Remove two screws and the wiper arm park ramp from the vehicle.
    Fig 1: Removing Two Screws & Wiper Arm Park Ramp From Vehicle
    G01476441Courtesy of GENERAL MOTORS CORP.
