Installation Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the hose to the liftgate inner panel using 2 hose clips.
  2. Connect the hose to the liftgate harness.
  3. Connect the hose to the liftgate inner panel.
  4. Install the liftgate trim panel. Refer to TRIM PANEL REPLACEMENT -- LIFT GATE in Body Rear End.
    Fig 1: Connecting Hose To Liftgate Inner Panel
    G01476402Courtesy of GENERAL MOTORS CORP.
