Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.

Remove the front speaker grille from the vehicle.
Refer to SPEAKER REPLACEMENT -- FRONT in Entertainment.

Fig 1: Removing Front Speaker Grille From Vehicle
Courtesy of GENERAL MOTORS CORP.
Turn the sensor counter-clockwise 1/4 turn in order to remove.
Disconnect the electrical connection from the DRL ambient light sensor.

Fig 2: Turning Sensor Counter-Clockwise 1/4 Turn To Remove
Courtesy of GENERAL MOTORS CORP.
