Installation Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.

Using the J 38185 install the radiator inlet hose clamp to the coolant outlet.

Fig 1: Installing Radiator Inlet Hose
Courtesy of GENERAL MOTORS CORP.
Using the J 38185 reposition the radiator inlet hose clamp to the radiator.
Install the radiator inlet hose to the radiator support.
Fill the cooling system. Refer to DRAINING AND FILLING COOLING SYSTEM .
Install the air cleaner outlet resonator.

Fig 2: Repositioning Radiator Inlet Hose Clamp
Courtesy of GENERAL MOTORS CORP.
Inspect the cooling system for leaks.
