Installation Procedure

WARNING: This page is about a different car, the 2003 Pontiac Aztek and 2003 Buick Rendezvous. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the rear wiper blade onto the rear wiper arm. Refer to WIPER ARM BLADE REPLACEMENT - REAR  .
  2. Align the rear wiper blade with the mark on the rear window.
  3. Install the rear wiper arm onto the rear wiper motor spindle.
  4. Install the rear wiper arm nut.

    Tighten

    Tighten the nut to 25 N.m (18 lb ft).

  5. Install the cap to the rear wiper arm.
  6. Remove the mark from the rear window.
    Fig 1: Installing Rear Wiper Arm
    G01517370Courtesy of GENERAL MOTORS CORP.
