Installation Procedure

WARNING: This page is about a different car, the 2003 Pontiac Aztek and 2003 Buick Rendezvous. However, it is still accessible from the selected car via links, so may be relevant.
  1. Position the rear washer pump to the washer solvent container pressing in until fully seated.
  2. Connect the rear hose to the rear washer pump.
  3. Connect the rear washer pump electrical connector.
  4. Fill the washer solvent container with washer solvent.
  5. Close the hood.
    Fig 1: Connecting Rear Washer Pump Electrical Connector And Rear Hose
    G01517358Courtesy of GENERAL MOTORS CORP.
