Oil Pan Installation

WARNING: This page is about a different car, the 2003 Pontiac Aztek and 2003 Buick Rendezvous. However, it is still accessible from the selected car via links, so may be relevant.
  1. Apply sealer GM P/N 12346141, Canadian P/N 10953433 or the equivalent to both sides of the crankshaft rear main bearing cap (1). Press sealer into gap using a putty knife.
    Fig 1: Identifying Sealer Applying Width On Crankshaft Rear Main Bearing Cap
    G01500830Courtesy of GENERAL MOTORS CORP.
  2. Install the oil pan gasket.
  3. Install the oil pan.
  4. Install the oil pan bolts.

    Tighten  Tighten the oil pan bolts to 25 N.m (18 lb ft).

  5. Install the oil pan side bolts.

    Tighten  Tighten the oil pan side bolts to 50 N.m (37 lb ft).

    Fig 2: Installing Oil Pan
    G01500831Courtesy of GENERAL MOTORS CORP.
