Engine Mount Strut and Air Conditioning Compressor Bracket Removal

WARNING: This page is about a different car, the 2003 Pontiac Aztek and 2003 Buick Rendezvous. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the engine mount strut and A/C compressor bracket bolts.
  2. Remove the engine mount strut and A/C compressor bracket.
    Fig 1: Removing Engine Mount Strut And A/C Compressor Bracket
    G01500618Courtesy of GENERAL MOTORS CORP.
