Differential Clutch Pump Actuator Check Valve

WARNING: This page is about a different car, the 2003 Pontiac Aztek and 2003 Buick Rendezvous. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Differential Clutch Pump Actuator Check Valve Connector Terminals
G01499934Courtesy of GENERAL MOTORS CORP.
