Removal Procedure

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2003 GMC Yukon XL, 2003 GMC Yukon, 2003 Chevrolet Tahoe, 2003 Chevrolet Suburban, and 2003 Chevrolet Avalanche. However, it is still accessible from the selected car via links, so may be relevant.
  1. Set the front wheels in the straight-ahead position.
  2. Set the steering wheel in the LOCK position.
  3. Remove the intermediate shaft. Refer to INTERMEDIATE STEERING SHAFT REPLACEMENT - LOWER  .
  4. Remove the nuts from the studs.
  5. Remove the seal from the vehicle.
    Fig 1: Removing Steering Column Seal & Nuts
    G01455178Courtesy of GENERAL MOTORS CORP.
