Removal Procedure

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2003 GMC Yukon XL, 2003 GMC Yukon, 2003 Chevrolet Tahoe, 2003 Chevrolet Suburban, and 2003 Chevrolet Avalanche. However, it is still accessible from the selected car via links, so may be relevant.
  1. Drain the cooling system. Refer to DRAINING AND FILLING COOLING SYSTEM in Engine Cooling.
  2. Remove the air intake tube.
  3. Remove the heater and surge tank hoses from the mounting clip.
  4. Squeeze the plastic retainer release tabs.
    Fig 1: Squeezing Plastic Retainer Release Tabs
    G01454299Courtesy of GENERAL MOTORS CORP.
  5. Pull the connection apart.
    Fig 2: Pulling Connection Apart
    G01454300Courtesy of GENERAL MOTORS CORP.
  6. Remove the outlet heater hose from the radiator.
  7. Remove the outlet heater hose (1).
    Fig 3: Removing Outlet Heater Hose From Radiator
    G01454301Courtesy of GENERAL MOTORS CORP.
