Removal Procedure

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2003 GMC Yukon XL, 2003 GMC Yukon, 2003 Chevrolet Tahoe, 2003 Chevrolet Suburban, and 2003 Chevrolet Avalanche. However, it is still accessible from the selected car via links, so may be relevant.
  1. Open the door.
  2. Pull the roof drip molding from the pinchweld and the windshield molding flange.
    3. Fig 1: Removing Front Door Upper Weatherstrip
    G01458956Courtesy of GENERAL MOTORS CORP.
