Removal Procedure

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2003 GMC Yukon XL, 2003 GMC Yukon, 2003 Chevrolet Tahoe, 2003 Chevrolet Suburban, and 2003 Chevrolet Avalanche. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the push pins from the wheel opening flare.
  2. Starting from one end of the flare remove the wheel opening flare from the front fender.
  3. Clean the area in order to remove any dirt or adhesive from the fender.
    4. Fig 1: Removing Rear Wheel Opening Flare
    G01458455Courtesy of GENERAL MOTORS CORP.
