Installation Procedure

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2003 GMC Yukon XL, 2003 GMC Yukon, 2003 Chevrolet Tahoe, 2003 Chevrolet Suburban, and 2003 Chevrolet Avalanche. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: Refer to FASTENER NOTICE in Cautions and Notices.

Install the rear axle drain plug.
Tighten

Tighten the rear axle drain plug to 33 N.m (24 lb ft).
Fill the rear axle. Use the proper fluid.

Fig 1: Install The Rear Axle Drain Plug (9.5, 10.5 Inch Axle)
Courtesy of GENERAL MOTORS CORP.
Install the rear axle fill plug.
Tighten

Tighten the rear axle fill plug to 33 N.m (24 lb ft).
Lower the vehicle.

Fig 2: Install The Rear Axle Fill Plug (9.5, 10.5 Inch Axle)
Courtesy of GENERAL MOTORS CORP.
