Valve Lifter Installation

WARNING: This page is about a different car, the 2002 GMC Savana and 2002 Chevrolet Chevy Express. However, it is still accessible from the selected car via links, so may be relevant.

Apply lubricant GM P/N United States 12345501, GM P/N Canada 992704, or equivalent, to the valve lifter rollers.
Important: If reusing the valve lifters, install the valve lifters in the original positions.
Install the valve lifters.

Fig 1: Valve Lifters
Courtesy of GENERAL MOTORS CORP.

NOTE: Refer to FASTENER NOTICE .
Install the valve lifter pushrod guides.
Tighten

Tighten the valve lifter pushrod guide bolts to 16 N.m (12 lb ft).

Fig 2: Valve Lifter Pushrod Guides
Courtesy of GENERAL MOTORS CORP.
