Removal Procedure

WARNING: This page is about a different car, the 2002 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the grille. Refer to GRILLE REPLACEMENT .
  2. Remove the hood latch. Refer to Hood Latch Replacement .
  3. Remove the hood latch support nuts (2) from the hood latch support (3).
  4. Remove the hood latch support bolts (1) from the hood latch support (3).
  5. Remove the hood latch support (3) from the vehicle.
    Fig 1: Removing Hood Latch Support
    G01780139Courtesy of GENERAL MOTORS CORP.
