Installation Procedure

WARNING: This page is about a different car, the 2002 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.
  1. Coat the camshaft rear bearing hole plug with sealer. Use GM P/N 1052080 or an equivalent.
  2. Install the camshaft rear bearing hole plug.
  3. Install the flywheel. Refer to Engine Flywheel Replacement  .
    Fig 1: Installing Camshaft Rear Bearing Hole Plug
    G01810995Courtesy of GENERAL MOTORS CORP.
