Installation Procedure

WARNING: This page is about a different car, the 2002 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the door auxiliary sealing strip (1) to the door frame. Ensure that the fasteners lock into position.
  2. Install the outer belt sealing strip.
    Fig 1: Installing Front Door Lower Auxiliary Sealing Strip
    G01780392Courtesy of GENERAL MOTORS CORP.
