Installation Procedure

WARNING: This page is about a different car, the 2002 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the seat back latch to the rear package self.
    CAUTION: Refer to FASTENER NOTICE .
  2. Install the seat back latch bolts to the latch.

    Tighten

    Tighten the bolts to 25 N.m (18 lb ft).

    Fig 1: Installing Seat Back Latch
    G01780634Courtesy of GENERAL MOTORS CORP.
  3. Install the seat back release handles to the rear package shelf.

    Press the seat back release handles into the rear package shelf until fully seated.

  4. Install the rear window panel trim. Refer to TRIM PANEL REPLACEMENT - REAR WINDOW SHELF .
  5. Close the rear compartment lid.
  6. Check the seat back latch for proper operations.
    Fig 2: Installing Seat Back Release Handles
    G01780635Courtesy of GENERAL MOTORS CORP.
