Installation Procedure

WARNING: This page is about a different car, the 2002 GMC Yukon XL, 2002 Chevrolet Suburban, and 2002 Chevrolet Avalanche. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: View Of Oil Level Sensor
    GM750962Courtesy of GENERAL MOTORS CORP.
    NOTE: Refer to FASTENER NOTICE in Cautions and Notices.
  1. Install the oil level sensor to the oil pan.

    Tighten:  Tighten the sensor to 20 N.m (15 lb ft).

    2. Fig 2: Oil Level Sensor Electrical Connector
    GM750961Courtesy of GENERAL MOTORS CORP.
  2. Connect the oil level sensor electrical connector (2).
  3. Fill the engine oil. Refer to Engine Oil and Oil Filter Replacement .
