Removal Procedure

WARNING: This page is about a different car, the 2002 Oldsmobile Aurora and 2001 Oldsmobile Aurora. However, it is still accessible from the selected car via links, so may be relevant.

Important: Observe the striker location and the number of spacers before removing the striker fasteners.

Mark the location of the door striker on the pillar with a grease pencil.
Remove the door striker fasteners (1).
Remove the striker (2), spacer (3) and washer.

Fig 1: Removing Door Striker

Courtesy of GENERAL MOTORS CORP.
